The best LED flood light manufacture for sale led high mast light factory for old mobile tower lights replacing and updating

What is mobile tower lights

Main structure: The mobile tower lights is a system composed of trailers, lifting masts, power supplies, and lighting equipment. The individual body towed by the vehicle can also be modified from existing trucks and various trucks. The lifting mast, lighting equipment and other equipment are reasonably installed on the trailer and combined together to form a complete movable lighting system. The mobile tower lights is easy to transport to places that temporarily require large-scale lighting, and is very convenient to use.

Reducing energy consumption is an important measure to ensure the continuous use of mobile light towers, so our Green Light LED has always designed high-brightness LED for mobile tower lights solutions. We can provide 100-5000W LED to meet the different needs of mobile tower lights .

Pls check the blew link to see the product detail information:

CYCLOPS SERIES 240W-1800W

Technical requirements for mobile tower lights

1.Applicable places: suitable for mobiletowerlights and emergency lighting in large-scale power repair operations.

2.Light source: Four high-efficiency energy-saving lamp holders are used, the service life is more than 50,000 hours, and the luminous flux is 120000-6000000 LM and above.

3.Housing: The lamp uses a hydraulic telescopic cylinder as the lifting adjustment method. The entire lighthouse and lifting rod are made of high-strength alloy materials, which can realize automatic lifting adjustment, and the maximum lifting height is 8-15 meters; the lamp holder can adjust the lighting angle up and down, The light coverage radius reaches 120-150 meters.

The whole shell has strong resistance to strong impact and corrosion, and can be used under various harsh conditions. It has been used in the environment for a long time, and the protection level is above IP66.

4.Power supply: use imported high-performance generator set for power supply (engine power: 7KW or more). The generator set uses gasoline/diesel as fuel, can work continuously for more than 8 hours at a time, and can be connected to a 220 V municipal power supply. At the same time, the lighted generator provides external electrical output, which can supply power to other equipment.

5.Operation: The lifting rod can be raised and reversed through the remote control or manual mode. The operation is simple, safe and reliable. The operating range of the remote control mode is approximately 30 meters. Adopt shock absorber, wheel hub, tire, same as car system, economical and durable. A variety of tractor head configurations can be applied to all types of vehicles in China, Europe and the United States. The towing speed is not less than 75KM/h, suitable for moving to various outdoor environments. Two taillights are installed at the tail of the lamp.

It is equipped with an integrated control system, control switches, control display and indicator meters, all of which are integrated on the control panel.

The same panel is convenient for operators to operate and monitor in real time. Each operation command is completed by one-key start and humanized operation. At the same time, it is equipped with unit start-up and fault alarm devices, which can perform self-protection and automatic shutdown.

The most important thing is the selection of LED when newly supporting the mobile tower lights. The performance is too poor, which will affect the use of the scene. However, the cost of LED with better performance is too high. So Green light LED is committed to helping customers solve this concern. Design LED flood light with excellent performance and low cost. For details, please contact us for information.[email protected].

The performance and characteristics of the mobile tower lights

1.The unique large-scale lampshade design allows the light to be emitted in a straight line, providing the best lighting effect for the construction site. Without any tools, each light can be adjusted independently. The fast power connection makes transportation before disassembly easier. The main mast can be rotated 360 degrees so that the lights can be adjusted according to different needs after being raised. The compact enhanced lighthouse provides extraordinary lighting. The enhanced and mounted light tower adopts a compact and light design, and the transportation is convenient.

2.Adopt 4 LED lights of 200 watts, 300 watts, 500 watts or 1000 watts, the lamp head can change the projection angle arbitrarily within the range of 0°~90° in the vertical direction; the maximum height of the lamp pole is 9 meters, and the rising time is about 50S, the fall time is about 20S, and the light coverage radius can reach 120 meters to 150 meters.

3.The light pole can rotate 360° in the horizontal direction, and there is no dead angle for 360° irradiation. The light pole is integrated with the body, and must be kept vertical after being put down, and it must not be folded for transportation or movement.

4.The control switch, control display and indicating instrument are all integrated on the same panel, which is convenient for the operator to perform real-time operation and monitoring.

5.Fully automatic operation, start the engine group, raise and lower the light pole, retract and release the hydraulic foot, all the lighting switches are independently controlled by a button

6.The whole set of lighthouse adopts 4 hydraulic supporting feet and adopts fully automatic operation design. When the supporting foot is retracted, it can be locked with a pin buckle and will not be accidentally released. After the hydraulic feet are deployed, they can support a load of more than 1400kg, and each support foot can carry 350kg (one-button automatic deployment foot); it can ensure safe work under 8 strong winds.

7.Lamp power: 4×1000W; Luminous flux: 4×1500000lm. Electrical performance: 220V~50Hz. Vertical flip (electric) 0°~90°. Enclosure protection grade IP66.

8.Generator parameters: select 0# diesel, engine rated power 7.2KW (50Hz). Fuel consumption: 2Lh. Fuel tank capacity: 80L. Continuous working time: 40h. Electrical system: 12V. Noise (7 meters): 75db. The insulation resistance is 400 megohms.

9.There are two tail lights at the rear of the lighthouse, which are connected to the electric car to achieve braking and lighting functions. The trailer must have a braking device to prevent the lighthouse from slipping during use and storage.

Green Light LED products can be absolutely convenient whether it is for the new mobile tower lights or the replacement of the mobile tower lights. There is no need to make too many changes to the original configuration, so that it can be less costly. Pay, and worry about the complexity of upgrading the mobile tower lights.

The main service industries and scenarios of mobile tower lights

1.Architectural lighting. Used in engineering construction, urban construction pipelines, paving, road maintenance, roads Rescue;

2.Emergency lighting. Used for emergency rescue, earthquake preparation, armed police fire fighting, earthquake relief, flood prevention and rescue;

3.War preparation lighting. Used for emergency preparation, various rescues, field training, camping and distribution;

4.Mine lighting. Used for open-pit mine lighting, mine tunnel lighting, distributed storage and transportation, and Camping in the mine;

5.Mobile tower lighting. Used for sports events, film and television shooting, airport backup, railway power;

6.Emergency lighting. Used in transportation, electricity, water pipes, natural gas and telecommunications buildings.

Green Light LED products have a long life guarantee. Using international brands of power drivers and chips, coupled with a patented design of heat dissipation structure, the quality and reliability of products far beyond the supermarket. According to the working time of 5 hours a day, it can be used stably for 28 years.

Conclusion

Choosing Green Light mobile tower lights can not only reduce maintenance costs and increase return on investment (ROI). By choosing a suitable and stable supplier, we can safely purchase products and develop target markets without worrying about the supply of goods, which can save a lot of trouble. Necessary losses and troubles.

As a leader in high-power lighting, Green Light has a group of highly qualified and experienced technicians. It has developed advanced photoelectric R&D laboratories, CNC automation equipment manufacturing, and has a complete quality control system and production system. The materials used are shipped out of the factory. The finished products are strictly controlled and strictly inspected before. There are very successful project cases all over the world.

If you are looking for mobile tower lights, please do not hesitate to contact our green light team immediately, we will design a reasonable and most cost-effective lighting solution for you for free. [email protected].
