LED track lighting is a powerful outdoor pole type lighting fixture. LED sports track lights are equipped with narrow beam optical elements that can illuminate specific locations on the track surface. The power range is from 600 watts to 2000 watts. The lumen range is from 96000 to 320000 lumens. The voltage options are 100-277V and 277-480V.

LED track lights are a special type of strong pole type outdoor light equipped with various compact optical components. It features high wattage and high lumen fixtures, and is equipped with a range of narrow beam angles.

Green light LED that is possible to change the direction of light trajectory to avoid the generation of glare caused by overflow light.Thus protecting the eyes of athletes and spectators.

What are the benefits of using LED lights on the track?

High output high-quality light source: providing excellent nighttime viewing experience for drivers and fans

Reduce utility lighting costs: Save 50% or even more

Reduce maintenance costs: No need to replace light bulbs or ballasts

Start immediately: No need for prolonged preheating

Improve driver safety: Create balanced lighting that allows drivers to see dangerous situations and avoid them.

LED lights do not flash: they produce a constant light source. Flashing lights can distract the driver’s attention and cause eye fatigue.

High impact resistance level: able to withstand accidental impacts in racing sports

Easy replacement of metal halide lamps: We can replace 400 watt, 1000 watt, or even 2000 watt metal halide lamps one-on-one.

Waterproof lighting: All of our LED track lights have been certified with IP protection level. This is helpful for tracks located in damp areas.

Our lighting fixtures can be fixed to wooden pole structures with bolts: ensuring that the rated value of the pole can withstand the weight and load of the lighting fixtures. If you need, we also provide poles.

Long lifespan: The service life of track LED lights should be over 10 years.

We offer a variety of optical kits: We will provide you with lighting solutions that include the most suitable optical components for your track

Low and high voltage options: Choose from 100V to 480V.

1.Track brightness (lux) lighting requirements

Adequate illumination is crucial for racing drivers on the track. High speed racing is different from regular driving, it requires full concentration. Racing drivers must deal with any emergency situations on the track. The minimum requirement for track floodlights is 700 to 1000 lux, and the maximum horizontal and vertical illumination can reach 1500 to 2000 lux, depending on the specific needs of racing associations such as NYRA.

2.Lighting uniformity

In addition to brightness level, track lighting should also be ‘uniform’. The term ‘uniform lighting’ refers to the uniform distribution of lux on the track. This parameter indicates whether there is peak brightness in a specific area. If the lux level of all sampling points is the same, the illumination uniformity is 1 (maximum value).

In general, a lighting uniformity of 0.5 to 0.6 is sufficient. We offer LED racing lighting solutions with a uniformity of 0.7 to 0.8, providing you with an unparalleled lighting experience and enhancing user experience.

3.Color rendering index (CRI)

The Color Rendering Index (CRI) represents the degree of realism of the colors we can see under light. The maximum value of CRI is 100, which is equivalent to sunlight. Due to the color distortion of the Grand Tourer under low CRI lighting (60), this is an important parameter to consider when selecting the optimal lighting.

4.Non flickering lighting for racing cars

Viewers and journalists may want to film luxury sports cars and capture exciting moments. Almost everyone now owns a smartphone capable of shooting 4K or slow motion videos (240 fps, 960 fps). Our advanced lighting is suitable for high-speed photography up to 6000 Hz (flicker rate of 0.3%).

Conclusion

We have been a stadium lighting/ high mast light manufacturer for more than 15 years. If you want to improve your racing field lighting, please feel free to contact us via email [email protected], we will provide you with the design for free.
